Item Name: |
HSUN-G3-T10 1 LED+4 LED No Polarity Canbus LED |
Operating Voltage Available: Unit: VDC |
12 VDC or 6-30 VDC |
|
Base: |
T10,W5W,194,501 |
Operating Current: Unit: mA |
180 mA |
|
LED Chip: |
LED SMD5050(1 pc) |
Power Consumption: Unit: W |
2.52 W |
|
Brand: |
HSUN |
Luminous Flux: Unit: Lumen |
54 LM |
|
Beam Pattern: |
360° |
Operating Temperature Range: |
-30°C - + 85°C |
|
Color: |
white, blue red, green ,amber ,pink, purple etc, all colors are available |
||
|
Storage Temperature Range: -40°C to +100°C --- Up to 50,000 hour life span |
|||
G3 Canbus LED Characteristic:
1.G3 Canbus LED with Power Constant Current design , when the operating voltage changes, the power comsumption doesn't change, so 100%
never burned on the car under condition of 17V, and the instantaneous operating voltage can reach to 20V.Meanwhile, the G3 Canbus LED can
light steady when operating voltage is 6V.
2.Our engineers designe a protecting circuit on G3 Canbus LED to protect the led chips, so the led chips 100% work more steady and longer
lifetime.if the operating voltage is more than 20V, the resistors of G3 Canbus LED will be easy fall off , but the LED chips never burned, still can
light steady, only not canbus function
3. If customers don't want to put the resistors on G3 Canbus LED(without Cabbus function), then LED can work steady on the operating voltage
from 6V to 30V, so this seires LED can work steady on motocycle , car or truck. Please check below pictures with resistors and withou resistors.
More Detail:
1. white, blue red, green ,amber, pink, purple etc, all colors are available
2.Packing Specification :Anti-Electrostatic Polybag or Blister card
3.Warranty Time :24 months
4.Terms of payment : T/T , Western Union, PayPal, Escrow
5. Usage : Car Signal Light, Auto Indicator Light, Auto Pilot Lamp,501 Side Light
The LED with canbus system fit for almost those luxury cars manufactured after 2002 year.With normal led usually need to add extra resistors, but with canbus led can solve the error problem.
