Item Name: |
HSUN-G2-T10 8 LED SMD1210A No Polarity Canbus LED |
Operating Voltage Available: Unit: VDC |
12 VDC |
|
Base: |
T10,W5W,194,501 |
Operating Current: Unit: mA |
170 mA |
|
LED Chip: |
LED SMD3528 (Super Bright 1 Chip) |
Power Consumption: Unit: W |
2.38 W |
|
Brand: |
HSUN |
Luminous Flux: Unit: Lumen |
64 LM |
|
Beam Pattern: |
360° |
Operating Temperature Range: |
-30°C - + 85°C |
|
Color: |
white, blue red, green ,amber ,pink, purple etc, all colors are available |
||
|
Storage Temperature Range: -40°C to +100°C --- Up to 50,000 hour life span |
|||
G2 Canbus LED Characteristic:
HSUN LED as a first factory in China to produce canbus LED,according the special bad situations of G1(first generation) canbus led :1.easy to be burned
2. the weilded point of G1 canbus led tail is easy to fall off when the start voltage of luxury is more than 14V,as we known,the start voltage of some
car even reach to 16V, our engineers madea a G2(second generation)canbus led with line constant current , which are fit for those cars( start
voltage is more than 14V, even 16 V).
More Detail:
1. white, blue red, green ,amber, pink, purple etc, all colors are available
2.Packing Specification :Anti-Electrostatic Polybag or Blister card
3.Warranty Time :24 months
4.Terms of payment : T/T , Western Union, PayPal, Escrow
5. Usage : Car Signal Light, Auto Indicator Light, Auto Pilot Lamp,501 Side Light
The LED with canbus system fit for almost those luxury cars manufactured after 2002 year.With normal led usually need to add extra resistors, but with canbus led can solve the error problem.
These T10 W5W 501 canbus led built-in load resistors which used for OBC and without flickering problem, also avoid warning message on the dashboard lights up,
especially for modern computer cars (Audi, BMW, Mercedes, Porsche or Volkswagen ).
