1.The light source of in the front of the 9.5W and 11W High Power LED is combined with high brightness of the original America CREE 5W chip, the luminous efficiency increased by 200% compare to the former two types 6w and 7.5w

2.The unique top PCB design with holes, better heat dissipation, double constant current circuit design to make the lifetime up to 50,000 hours

3. Two group Constant Current Driver working on separately to get the maximum brightness efficiency.

4. the overall brightness enhanced obviously

5. Double lens design on the front of the light (internal CREE little lens + external big lens), stronger air-penetration, range farther, to ensure safety when drive in rainy day with 9.5w and 11w high power led as fog light.

Item Name:

HSUN-BA15S 9.5W HP LED

Spotlight

Operating Voltage Available:

Unit: VDC

9-32 VDC

Base:

BA15S, P21W, 1156

Operating Current:

Unit: mA

330 mA

LED Chip:

5W CREE+ 3*1.5W HP LED

Power Consumption:

Unit: W

4.62 W

Brand:

HSUN

Luminous Flux:

Unit: Lumen

460 LM

Beam Pattern:

360°

Operating Temperature Range:

-30°C - + 85°C

Color:

white, blue red, green ,amber ,pink, purple etc, all colors are available

Storage Temperature Range: -40°C to +100°C --- Up to 50,000 hour life span
Remark: we can produce with all kind of led chips as customers require ,pls contact HSUN
